| ISO norm |
ISO 4210-2 Road Racing bicycles |
| EN norm |
EN17406 Condition 2 For on and Off-Road riding and drops less than 15cm |
| LOAD CAPACITY |
120 Kg |
| FRAME |
Alu X6 Ultralite X-Road Race , Road Advanced Geometry, Smooth Welding, Disc Brake Flat mount, BB BSA 68mm, Integrated Cable Routing, Full Carbon front fork; mudguadrs ready |
| FORK |
X-ROAD Carbon Fork |
| BOTTOM BRACKET |
SHIMANO BB-RS501, BSA, shell 68mm |
| HEADSET |
ACROS AIX-643, ICR, OD56, IS52/28.6 - 40IPS |
| FRONT AXLE |
SB02, TA12x119, M12xP1.5x8.5L, Black |
| REAR AXLE |
SB02, TA12x165, M12xP1.5x14L, Black |
| SHIFTERS RIGHT |
SHIMANO GRX RX610, 12-speed |
| REAR DERAILLEUR |
SHIMANO GRX RD-RX822, Shadow Plus Design |
| CRANKSET |
SHIMANO GRX FC-RX610, 40T |
| CASSETTE |
SHIMANO SLX CS-M7101, 12-speed, 10-45T |
| CHAIN |
SHIMANO DEORE CN-M6100 |
| BRAKE FRONT |
SHIMANO GRX RX610, hydraulic disc brake |
| ROTOR FRONT |
SHIMANO SM-RT70, 160mm |
| BRAKE REAR |
SHIMANO GRX RX610, hydraulic disc brake |
| ROTOR REAR |
SHIMANO SM-RT70, 140mm |
| HUB FRONT |
SHIMANO HB-RS470, 28H, CL, 12x100mm, THRU Type AXLE |
| RIM FRONT |
DT Swiss R500, Disc, 28H, Tubeless Ready |
| TIRE FRONT |
Schwalbe G-One Allround, RaceGuard, TL-Easy, 40-622, ADDIX |
| HUB REAR |
SHIMANO FH-TC500-MS, 28H, CL, 12X142mm, THRU Type AXLE |
| RIM REAR |
DT Swiss R500, Disc, 28H, Tubeless Ready |
| TIRE REAR |
Schwalbe G-One Allround, RaceGuard, TL-Easy, 40-622, ADDIX |
| SPOKES |
SAPIM Race, Stainless Black |
| NIPPLES |
SAPIM, Brass |
| STEM |
ONE Race ICR, Alloy, 31,8mm, -7° |
| HANDLEBAR |
ONE Alloy, X-Race Aero, 31.8mm, Reach 70mm, Drop 127mm, Flare 2°, Backsweep 6° |
| GRIPS LEFT |
ONE Handlebar Tape |
| SADDLE |
Selle Royal SRX, 148mm |
| SEATPOST |
ONE Race, Alloy, 27.2mm |
| SEATPOST CLAMP |
ONE CC-080A, 31.8mm, Black |
